Product Details:
|
| Type: | Deep Groove Ball Bearing | Number: | 6311 C3 |
|---|---|---|---|
| WEIGHT: | 1.37 KG | Size: | 55x120x29mm |
| Clearance: | C3, C2, C4, C0, C5 | Sample: | 6-16 Working Days Depends On Quantity |
| Seals Type: | Open | Applicable Models:: | Auto Parts |
| High Light: | 29MM Width Deep Groove Ball Bearing,Deep Groove Ball Bearing 6311 |
||
Deep Groove Ball Bearing Specification
| INSIDE DIAMETER (MM):55MM |
| OUTSIDE DIAMETER (MM):120MM |
| WIDTH (MM):29MM |
| CAGE TYPE:STEEL |
| SEALS OR SHIELDS:OPEN TYPE |
| CLEARANCE:C3 |
| DYNAMIC LOAD RATING (KN):74.1 |
| STATIC LOAD RATING (KN):45 |
| FATIGUE LOAD RATING (KN):1.9 |
| REFERENCE SPEED RATING (R/MIN):12000 |
| LIMITING SPEED RATING (R/MIN):8000 |
Deep Groove Ball Bearing Description
Single row deep groove ball bearings are particularly versatile, have low friction and are optimized for low noise and low vibration, which enables high rotational speeds. They accommodate radial and axial loads in both directions, are easy to mount, and require less maintenance than many other bearing types.
Deep Groove Ball Bearing Product number
| Model | d | D | H | Cr | Cor | grease | oil | weight |
| (mm) | (mm) | (mm) | (kN) | (kN) | (r/min) | (r/min) | (kg) | |
| 6300 | 10 | 35 | 11 | 7.65 | 3.48 | 18000 | 24000 | 0.053 |
| 6301 | 12 | 37 | 12 | 9.72 | 5.08 | 17000 | 22000 | 0.06 |
| 6302 | 15 | 42 | 13 | 11.5 | 5.42 | 16000 | 20000 | 0.082 |
| 6303 | 17 | 47 | 14 | 13.5 | 6.58 | 15000 | 18000 | 0.115 |
| 6304 | 20 | 52 | 15 | 15.8 | 7.88 | 13000 | 16000 | 0.142 |
| 6305 | 25 | 62 | 17 | 20.6 | 11.3 | 11000 | 13000 | 0.232 |
| 6306 | 30 | 72 | 19 | 26.7 | 15 | 6600 | 12000 | 0.346 |
| 6307 | 35 | 80 | 21 | 33.4 | 19.3 | 8500 | 10000 | 0.457 |
| 6308 | 40 | 90 | 23 | 40.8 | 24 | 7000 | 8500 | 0.639 |
| 6309 | 45 | 100 | 25 | 52.8 | 31.8 | 6300 | 7500 | 0.837 |
Deep Groove Ball Bearing Applications
1. Material handling machinery:mining machinery, textile machinery, lifting equipment, Agricultural machinery: tractors, harvesting machinery, etc.
2. Heavy-duty mining machinery: metallurgical machinery, mining machinery, lifting machinery, loading and unloading machinery, industrial vehicles, cement equipment, etc.
3. Construction Machinery: forklifts, earth moving machinery, compaction machinery, concrete machinery, etc.
4. The general petrochemical machinery: oil drilling machinery, oil refining machinery, chemical machinery, gas compressors, paper machinery, printing machinery, etc.
5. Machine tools: forging machinery, foundry machinery, woodworking machinery, etc.
6. Car: truck, road, bus, car, modified car, motorcycle ,etc.
