Gu-8100 Universal Joint Bearing 47X131MM Low Friction

Gu-8100 Universal Joint Bearing 47X131MM  Low Friction
Gu-8100 Universal Joint Bearing 47X131MM  Low Friction
Gu-8100 Universal Joint Bearing 47X131MM  Low Friction Gu-8100 Universal Joint Bearing 47X131MM  Low Friction Gu-8100 Universal Joint Bearing 47X131MM  Low Friction

Large Image :  Gu-8100 Universal Joint Bearing 47X131MM Low Friction

Product Details:
Place of Origin: CHINA
Brand Name: QRL
Certification: ISO9001
Model Number: Gu-8100
Payment & Shipping Terms:
Packaging Details: Oem/Neutral
Delivery Time: 13 days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 10000pcs

Gu-8100 Universal Joint Bearing 47X131MM Low Friction

Description
Type:: Universal Joint Beairng NO:: Gu-8100
Oem: 0164-25-060 Size: 47X131MM
Certification:: ISO9001/2000 Product Name: Gu-8100
Application: Auto Parts Weight: 1.67KG
Highlight:

Gu-8100 Universal Joint Bearing

,

Universal Joint Bearing Low Friction



Gu-8100 Universal Joint Bearing 47X131MM


Universal Joint Bearing Specification



CROSS JOINT CUP DIAMETER 47MM, GREATEST WIDTH WITHOUT FASTENERS 131.1MM, segers are included, EXTERNAL LOCKING, GREASE NIPPLE, DODGE, DAF, FORD, IKARUS, MACK, MAN, 47X131.1, TOYOTA LANDCRUISER,


Universal Joint Bearing Description

Structure Universal joint consists of spider(cross) and 4 grease-filled roller bearings. It can transmit large torque at low friction. Spider with journal pegs and bearing cases as outer ring were hot forged or cold formed and machined. They are later carburized in furnace so that increased ruggedness and wear resistance are obtained. Parts are finally ground to designed size under severe tolerance. Oil seal as well as dust cover are also in use to protect internal journal area from intrusion of foreign material. Variety of grades and materials are selected to respond to extreme conditions such as very hot / very cold temperatures.

Universal Joint Bearing Product number

NISSAN
Type Part No D mm O mm L mm Spice No Original No KOYO MATSUBA
A GUN-26 23.82   61.3   37125-11975 N2461 UJ110
B GUN-27 25 40   RUJ-1781 37125-14627 N2563 UJ111
B GUN-28 20.01 35 57 RUJ-1780 37125-18025 N2057
B GUN-29 28 53   RUJ-2028 39625-21025 N2880BA UJ112
A GUN-30 30.188   92.08   37125-85461 N3092
IA GUN-31 32   107 K5-A564 37125-50001 N32111 UJ114
A GUN-32 35.5   119.2 K5-A568 37125-58026 N36119 UJ115
IB GUN-33 43   128 K5-A575 37125-99901 ND43128 UJ119
B GUN-34 25 52   RUJ-2040 37125-76025 N2580 UJ113
B GUN-35 32 64 91.8   37125-01J25
A GUN-36 25   77.6   37125-4101(6510) NP2578 UJ120
B GUN-38 26 45.6     37125-68200   UJ121
IA GUN-41 43   136 K5-A547 37125-90128 ND43142 UJ120
IA GUN-43 55.1   163.8 K5-A548 37125-90027 ND43128B UJ125
A GUN-44 20.5   56.6   48155-99000   UJ118
A GUN-45 20.7   52.4 K5-A648 37125-H8500
B GUN-46 27 46   RUJ-1700 37126-01G25   UJ124

Universal Joint Bearing Delivery

When the vehicle is running, because the direction of torque transmission is the same, the direction of force on the cross shaft is also the same. Over time, the unilateral wear of the cross shaft journal is caused. As time goes by, the force side of the cross shaft will wear more and more, and grooves will cause looseness and noise. You can use the cross shaft to rotate 90° relative to the original position, which can extend the use time. When assembling, pay attention to the side with the oil nozzle facing the drive shaft. The universal joint fork should rotate freely on the cross shaft, and there should be no jamming, and there should be no axial gap. Grease should be injected frequently in daily maintenance to prevent the wear of the cross shaft journal and bearings due to lack of grease.

Gu-8100 Universal Joint Bearing 47X131MM  Low Friction 0Gu-8100 Universal Joint Bearing 47X131MM  Low Friction 1
